加压式捏炼机技术参数 |
|
|
|
|
型号Type | X(S)N35 | X(S)N55 | X(S)N75 | X(S)N110 |
捏合总容积( L) Total Volume of mixing chamber | 75 | 125 | 180 | 250 |
密炼总容积(L) Working Volume of mixing chamber | 35 | 55 | 75 | 110 |
驱动电机功率( KW) Driving motor power | 55 | 75 | 110 | 185 |
翻转油泵电机功率( KW)Tilting motor power | 5.5 | 5.5 | 5.5 | 7.5 |
翻转角度Tilting angle | 110° | 110° | 110° | 110° |
转子转数(前后)( r/min)Rotational speed of the rotor(front/rear) | 36/30 | 36/30 | 36/30 | 30/24.5 |
压缩空气工作压力( Mpa) Pressure of compressed air | 06-0.8 | 06-0.8 | 06-0.8 | 06-0.8 |
冷却水压力( Mpa) Cooling water pressure | 0.3 ~ 0.4 | 0.3 ~ 0.4 | 0.3 ~ 0.4 | 0.3 ~ 0.4 |
外形尺寸长×宽×高( mm)Size:Length×Width×Height | 3150x1990x2880 | 3280x2120x3090 | 3250x2210x3250 | 4075x2712x3580 |
